35" Diffusion Pump

CVC Model PMC-32C, 35" Diffusion Pumps (Today this is the Varian HS-35.
Varian purchased CVC rights to this pump.) Can be purchased either in As-Is condition or in Rebuilt condition with a warranty. 35" Throat Diameter.
Bolt Circle is approx. 38-3/4" with 14 Holes on approx. 8-9/16" Centers. Flange
O.D. is 41-3/4". O-Ring Center Diameter is 36-1/8". Approx. 72-3/4" Overall Height (79" on 48" x 48" shipping pallet).
Note: Mating 35" Cryo-Baffle is also available for improved low-range vacuum and elimination of backstreaming (See Item# 3161 Below). 6" Foreline with approx. 9-1/2" Bolt Circle with 8 Holes on approx. 3-5/8" Centers. 1/4" dia. O-ring is approx. 8-7/8" diameter to center. Shipping Wt. with pallet approx. 2050 lb.
Price in As-Is Condition: $ 4,200.00
Price in Warranty Rebuilt Condition, Painted: $ 8,200.00 (with existing working elements. Add $6,000 if you want brand new elements.)
Location: Coeur d'Alene, Idaho 83814 (As-Is) or S. California (Rebuilt)
